2-5
Cisco SCE8000 GBE Installation and Configuration Guide
Chapter 2 Introduction to the Cisco SCE 8000 10 GBE Platform
Service Control Module (Cisco SCE 8000-SCM-E)
Table 2-3 Cisco SCE 8000-SCM-E LEDs
LEDs Description
Power
• Green—Installed power supplies are functioning normally.
• Amber—Only one power supply is functioning normally.
• Unlit—No power from either power supply.
Status The Status LED indicates the operational status of the Cisco SCE 8000 10 GBE
system, as follows:
• Unlit—No power from either power unit.
• Amber—The system is booting up.
• Flashing amber—The system is operational, but is in a warning state.
• Green—The system is fully operational.
• Red—There is a problem or failure
Note Alarms are hierarchical: Failure takes precedence over Warning, which
takes precedence over Operational.
Optical bypass
• Green—Optic bypass modules are present, but not operating.
• Amber—Optic bypass modules are present and operating.
• Unlit—Optic bypass modules are not present or there is no power.
On a slave Cisco SCE 8000-SMC-E module (in slot 2), this LED is always off.
Note This functionality is consistent even when the Cisco SCE 8000 10 GBE is
turned off.
Master Master Service Control module indicator.
• Steady green—Master Service Control module (in slot 1)
• Unlit—Slave Service Control module (in slot 2)
Port1 and Port2
(Management
interfaces)
The Port1 and Port2 LEDs indicate the operational status of the Cisco SCE 8000
out-of-band LAN-based management port, as follows:
• Link/Active
Steady green—Port link is up
Flashing green—Activity on the port link
Unlit—Port link is down
• Speed
Unlit—Port is set to 10 Mbps
Steady green—Port is set to 100 Mbps
Steady amber—Port is set to 1000 Mbps
On a slave Cisco SCE 8000-SMC-E module (in the second slot), this LED is
always off.
