IP Configuration
IPv4 Management and Interfaces
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 303
16
• Reason—
- No Problem
- No Resource
- No Snoop VLAN
- Trust Port
STEP 2 To add an entry, click Add.
STEP 3 Enter the fields:
• VLAN ID—VLAN on which packet is expected.
• MAC Address—MAC address of packet.
• IP Address—IP address of packet.
• Interface—Unit/Slot/Interface on which packet is expected.
• Type—The possible field values are:
- Dynamic—Entry has limited lease time.
- Static—Entry was statically configured.
• Lease Time—If the entry is dynamic, enter the amount of time that the entry is to be
active in the DHCP Database. If there is no Lease Time, check Infinite.)
STEP 4 Click Apply. The settings are defined, and the device is updated.
DHCP Server
This section covers the following topics:
•Overview
• Properties
•Network Pool
• Excluded Addresses
• Static Hosts
• DHCP Options
