Cisco SF350-24P Administration Guide

IP Configuration: VRRP
Configuring VRRP
355 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
19
• Master Parameters
- Priority—255
- Advertisement Interval—Time interval, as described in VRRP Advertisements.
- Source IP Address—IP address to be used in VRRP messages.
VRRP Statistics
To view VRRP statistics and to clear interface counters:
STEP 1 Click IP Configuration > IPv4 Management and Interfaces > VRRP> VRRP Statistics.
The following fields are displayed for every interface on which VRRP is enabled:
• Interface—Displays the interface on which VRRP is enabled.
• Invalid Checksum—Displays number of packets with invalid checksums.
• Invalid Packet Length—Displays number of packets with invalid packet lengths.
• Invalid TTL—Displays number of packets with invalid time-to-live values.
• Invalid VRRP Packet Type—Displays number of packets with invalid VRRP packet
types.
• Invalid VRRP ID—Displays number of packets with invalid VRRP IDs.
• Invalid Protocol Number—Displays number of packets with invalid protocol
numbers.
• Invalid IP List—Displays number of packets with invalid IP lists.
• Invalid Interval—Displays number of packets with invalid intervals.
• Invalid Authentication—Displays number of packets that failed authentication.
STEP 2 Select an interface.
STEP 3 Click Clear Interface Counter to clear the counters for that interface.
STEP 4 Click Clear All Interface Counters to clear all the counters.

Cisco SF350-24P Specifications

General

Model	SF350-24P
Category	Switch
PoE Budget	195W
Layer	Layer 3
Power Supply	Internal
Uplink Ports	2 x combo Gigabit SFP + 2 x Gigabit
MAC Address Table Size	16K entries
Jumbo Frame Support	9216 bytes
Management	Web, CLI, SNMP
Features	QoS, VLAN, IPv6, ACLs
Dimensions	440 mm x 257 mm x 44 mm
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 90% non-condensing
Weight	3.48 kg
