Cisco SG350-28P Administration Guide

Administration: Stack Management
Unit ID Assignment
121 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
8
Unit ID Assignment
After topology discovery is completed, each unit in a stack is assigned a unique unit ID.
The unit ID is set in the Stack Management page in one of the following ways:
• Automatically (Auto)—The Unit ID is assigned by the topology discovery process.
• Manually—The unit ID is manually set to an integer from 1-maximum number of
units in a stack.
Duplicate Unit IDs
If you assign the same unit ID to two separate units, only one of them can join the stack with
that unit ID.
If auto numbering has been selected, the duplicate unit is assigned a new unit number. If auto
numbering was not selected, the duplicate unit is shut down.
The following shows a case where two units manually assigned the same unit ID. Unit 1 does
not join the stack and is shut down. It did not win the master selection process between the
master-enabled units (1 or 2).
Duplicate Unit Shut Down

Cisco SG350-28P Specifications

General

Model	SG350-28P
Category	Switch
Ports	28
PoE Ports	24
PoE Budget	195W
Switching Capacity	56 Gbps
Forwarding Rate	41.67 Mpps
Layer	Layer 3
Rack Mountable	Yes
Gigabit Ethernet Ports	28
MAC Address Table Size	16K
Power Supply	Internal
Jumbo Frame Support	Yes
Dimensions (W x D x H)	440 x 257 x 44 mm
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% non-condensing
