Cisco SG350-28P Administration Guide

IP Configuration
IPv6 Management and Interfaces
312 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
16
• Type—The manner in which the IP address was assigned to the client. The possible
options are:
- Static—The hardware address of the host was mapped to an IP address.
- Dynamic—The IP address, obtained dynamically from the device, is owned by the
client for a specified period of time. The IP address is revoked at the end of this
period, at which time the client must request another IP address.
• State—The possible options are:
- Allocated—IP address has been allocated. When a static-host is configured, its state
is allocated.
- Declined—IP address was offered but not accepted, therefore it is not allocated.
- Expired—The lease of the IP address has expired.
- Pre-Allocated—An entry will be in pre-allocated state from the time between the
offer and the time that the DHCP ACK is sent from the client. Then it becomes
allocated.
STEP 2 Click Delete. The Running Configuration file is updated.
IPv6 Management and Interfaces
This section covers the following topics:
•Overview
• IPv6 Global Configuration
• IPv6 Interfaces
•IPv6 Tunnel
• IPv6 Addresses
• IPv6 Router Configuration
• IPv6 Default Router List
• IPv6 Neighbors
• IPv6 Prefix List

Cisco SG350-28P Specifications

General

Model	SG350-28P
Category	Switch
Ports	28
PoE Ports	24
PoE Budget	195W
Switching Capacity	56 Gbps
Forwarding Rate	41.67 Mpps
Layer	Layer 3
Rack Mountable	Yes
Gigabit Ethernet Ports	28
MAC Address Table Size	16K
Power Supply	Internal
Jumbo Frame Support	Yes
Dimensions (W x D x H)	440 x 257 x 44 mm
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% non-condensing
