Cisco SG350-28P Administration Guide

Administration: Stack Management
Software Auto Synchronization in Stack
129 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
8
Connecting Units
Two units can only be connected in a stack if the stack ports on both ends of the link are of the
same speed. You must check that both ports support the same speed.
Cables Types
The following describes the cable types supported.
Software Auto Synchronization in Stack
All the units in the stack must run the same software version. Each unit in a stack
automatically downloads firmware from the master unit, if the firmware, which the unit and
the master are running, is different. The unit automatically reboots itself to run the new
version.
Stack Ports or Network Ports
Connector Type All ports
Cisco SFP-H10GB-CU1M – Passive Copper Cable 1G - 10G
Cisco SFP-H10GB-CU3M – Passive Copper Cable 1G - 10G
Cisco SFP-H10GB-CU5M – Passive Copper Cable 1G - 10G
Cisco SFP-10G-SR 10G
Cisco SFP-10G-LRM Not supported
Cisco SFP-10G-LR 10G
1G SFP Module MGBSX1 1G
1G SFP Module MGBT1 1G
1G SFP Module MGBLX1 1G
1G SFP Module MGBBX1 1G
100Mbs SFP Module MFELX1 Not supported
100Mbs SFP Module MFEFX1 Not supported
100Mbs SFP Module MFEBX1 Not supported
Other SFPs 1G

Cisco SG350-28P Specifications

General

Model	SG350-28P
Category	Switch
Ports	28
PoE Ports	24
PoE Budget	195W
Switching Capacity	56 Gbps
Forwarding Rate	41.67 Mpps
Layer	Layer 3
Rack Mountable	Yes
Gigabit Ethernet Ports	28
MAC Address Table Size	16K
Power Supply	Internal
Jumbo Frame Support	Yes
Dimensions (W x D x H)	440 x 257 x 44 mm
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% non-condensing
