Cisco SG350-28P Administration Guide

IP Configuration
IPv6 Management and Interfaces
Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4 331
16
- Description—Text.
• IPv6 Prefix—IP route prefix.
• Prefix Length—IP route prefix length.
• Greater Than—Minimum prefix length to be used for matching. Select one of the
following options:
- No Limit—No minimum prefix length to be used for matching.
- User Defined—Minimum prefix length to be matched.
• Lower Than—Maximum prefix length to be used for matching. Select one of the
following options:
- No Limit—No maximum prefix length to be used for matching.
- User Defined—Maximum prefix length to be matched.
• Description—Enter a description of the prefix list.
STEP 4 Click Apply to save the configuration to the Running Configuration file.
IPv6 Access Lists
The IPv6 access list can be used in MLD Proxy > Global MLD Proxy Settings > SSM IPv6
Access List page.
To create an access list:
STEP 1 Click IP Configuration > IPv6 Management and Interfaces > IPv6 Access List.
STEP 2 To add a new Access List, click Add and enter the following fields:
• Access List Name—Select one of the following:
- Use Existing List—Select a previously-existing access list.
- Create new list—Enter a name for the new access list.
• Source IPv6 Address—Enter the source IPv6 address. The following options are
available:
- Any—All IP addresses are included.
- User Defined—Enter an IP address.

Cisco SG350-28P Specifications

General

Model	SG350-28P
Category	Switch
Ports	28
PoE Ports	24
PoE Budget	195W
Switching Capacity	56 Gbps
Forwarding Rate	41.67 Mpps
Layer	Layer 3
Rack Mountable	Yes
Gigabit Ethernet Ports	28
MAC Address Table Size	16K
Power Supply	Internal
Jumbo Frame Support	Yes
Dimensions (W x D x H)	440 x 257 x 44 mm
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% non-condensing
