Cisco SG350-28P Administration Guide

IP Configuration: RIPv2
Access Lists
345 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
18
Access List Settings
To set the global configuration of an access list.
STEP 1 Click IP Configuration > IPv4 Management and Interfaces > Access List > Access List
Settings.
STEP 2 To add a new Access List, click Add to open the Add Access List page and enter the following
fields:
• Name—Define a name for the access list.
• Source IPv4 Address—Enter the source IPv4 address. The following options are
available:
- Any—All IP addresses are included.
- User Defined—Enter an IP address.
• Source IPv4 Mask—Enter the source IPv4 address mask type and value. The following
options are available:
- Network Mask—Enter the network mask.
- Prefix Length—Enter the prefix length.
• Action—Select an action for the access list. The following options are available:
- Permit—Permit entry of packets from the IP address(es) in the access list.
- Deny—Reject entry of packets from the IP address(es) in the access list.
STEP 3 Click Apply. The settings are written to the Running Configuration file.
Source IPv4 Access List
To populate an access list with IP addresses.
STEP 1 Click IP Configuration > > IPv4 Management and Interfaces > Access List > Source IPv4
Address List.
STEP 2 To modify the parameters of an access list, click Add and modify any of the following fields:
• Access List Name—Name of the access list.

Cisco SG350-28P Specifications

General

Model	SG350-28P
Category	Switch
Ports	28
PoE Ports	24
PoE Budget	195W
Switching Capacity	56 Gbps
Forwarding Rate	41.67 Mpps
Layer	Layer 3
Rack Mountable	Yes
Gigabit Ethernet Ports	28
MAC Address Table Size	16K
Power Supply	Internal
Jumbo Frame Support	Yes
Dimensions (W x D x H)	440 x 257 x 44 mm
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% non-condensing
