Security: IPv6 First Hop Security
Configuring IPv6 First Hop Security through Web GUI
457 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
26
Packet Drop Logging—Select to create a SYSLOG when a packet is dropped as a
result of a First Hop Security feature within this policy.
- Inherited—Use the value from the VLAN or the global configuration.
- Enable—Create a SYSLOG when a packet is dropped as a result of First Hop
Security.
- Disable—Do not create a SYSLOG when a packet is dropped as a result of First
Hop Security.
STEP 5 Click Apply to add the settings to the Running Configuration file.
STEP 6 To attach this policy to an interface:
Attach Policy to VLAN—Click to jump to Policy Attachment (VLAN) page where
you can attach this policy to a VLAN.
Attach Policy to Interface—Click to jump to Policy Attachment (Port) page where you
can attach this policy to a port.
RA Guard Settings
Use the RA Guard Settings page to enable the RA Guard feature on a specified group of
VLANs and to set the global configuration values for this feature. If required, a policy can be
added or the system-defined default RA Guard policies can be configured in this page.
To configure RA Guard:
STEP 1 Click Security > IPv6 First Hop Security > RA Guard Settings.
The currently-defined polices are displayed. For each policy, its Policy Type is displayed,
which indicates whether it is a default or user-defined policy.
STEP 2 Enter the following global configuration field:
RA Guard VLAN List—Enter one or more VLANs on which RA Guard is enabled.
Enter the other configuration fields that are described below.
STEP 3 To add a policy, click Add and enter the fields:
Policy Name—Enter a user-defined policy name.
Device Role—Displays one of the following options to specify the role of the device
attached to the port for RA Guard.
