Cisco TelePresence SX10 Quick Set Administrator Guide
Touch 10 physical interface
Ethernet with PoE:
for power and Ethernet
Mini-jack, 3.5 mm
(not in use)
Micro-USB:
for maintenance only
Two USB connectors
(not in use)
Not in use
Sound bar for audio
adjustment
Audio mute
Touch screen
Adjustable support
to accommodate
individual ergonomic
needs
Connect the Touch 10 controller (page 2 of 2)
