D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 103
Cisco TelePresence MX700 and MX800
API Reference Guide
xCommand Camera Ramp
Move the camera in a specified direction. The camera moves at specified speed until a stop
command is issued. In a daisy chain, you need to know the CameraId for the camera you want
to address. Be aware that pan and tilt can be operated simultaneously, but no other combina-
tions. In the latter case only the first operation specified is executed. For example, if you try to
run both zoom and pan at the same time, only zoom is executed.
NOTE: You must run a stop command to stop the camera, see the example below.
Requires user role: USER
USAGE:
xCommand Camera Ramp CameraId: CameraId [Pan: Pan] [PanSpeed: Pa nSpeed] [Tilt:
T ilt] [TiltSpeed: TiltSpeed] [Zoo m: Zoom] [ZoomSpeed: ZoomSpeed] [Focus: Focus]
where
CameraId: Integer (1..7)
Select the camera.
Pan: Left/Right/Stop
Move the camera to the Left or Right, followed by Stop.
PanSpeed: I nte ge r (1..15)
Set the pan speed.
Tilt: Down/Up/Stop
Move the camera Up or Down, followed by Stop.
TiltSpeed: Inte ge r (1..15)
Set the tilt speed.
Zoom: In/Out/Stop
Zoom the camera In or Out, followed by Stop.
ZoomSpeed: In teg er (1..15)
Set the zoom speed.
Focus: Far/Near/Stop
Focus the camera Far or Near, followed by Stop.
xCommand Camera TriggerAutofocus
Trigger the auto-focus functionality. The camera must support auto-focus functionality. If the
camera is daisy chained, the CameraId is given by its place in the chain.
Requires user role: USER
USAGE:
xCommand Camera TriggerAutofocus CameraId: CameraId
where
CameraId: Integer (1..7)
Select the camera to auto-focus.
