Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Cameras Camera [1..7] Backlight DefaultMode
This configuration turns backlight compensation on or off. Backlight compensation is useful
when there is much light behind the persons in the room. Without compensation the persons
will easily appear very dark to the far end.
Requires user role: USER
Default value: Off
USAGE:
xConfiguration Cameras Camera n Backlight Default Mode: DefaultMode
where
Default Mode : Off/On
Off: Turn off the camera backlight compensation.
On: Turn on the camera backlight compensation.
xConfiguration Cameras Camera [1..7] Brightness Mode
Define the camera brightness mode.
Requires user role: USER
Default value: Auto
USAGE:
xConfiguration Cameras Camera n Brightness Mode: Mode
where
Mode : Auto/Manual
Auto: The camera brightness is automatically set by the system.
Manual: Enable manual control of the camera brightness. The brightness level is set
using the Cameras Camera [n] Brightness DefaultLevel setting.
xConfiguration Cameras Camera [1..7] Brightness DefaultLevel
Define the brightness level. Requires the Cameras Camera [n] Brightness Mode to be set to
Manual.
Requires user role: USER
Default value: 20
USAGE:
xConfiguration Cameras Camera n Brightness DefaultLevel: DefaultLevel
where
Defa ultLevel : Integer (1..31)
The brightness level.
xConfiguration Cameras Camera [n..7] Focus Mode
This setting applies to Camera [2..7] for single camera systems, and to HDMI [3..7] for dual
camera systems.
Define the camera focus mode.
Requires user role: USER
Default value: Auto
USAGE:
xConfiguration Cameras Camera n Focus Mode: Mode
where
Mode : Auto/Manual
Auto: The camera will auto focus once a call is connected, as well as after moving the
camera (pan, tilt, zoom). The system will use auto focus only for a few seconds to set
the right focus; then auto focus is turned off to prevent continuous focus adjustments of
the camera.
Manual: Turn the autofocus off and adjust the camera focus manually.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco TelePresence MX700 Specifications

General

Product Type	Video conferencing system
Frame Rate	Up to 60 fps
Display	Dual 55-inch LCD
Audio	Integrated speakers and microphones
Video Standards	H.264
Network	Ethernet
Connectivity	HDMI, USB
Control	Touch 10 control unit
Video Resolution	1080p at 60 fps
Zoom	12x optical zoom
Codec	H.264
Network Protocols	SIP
Power Consumption	300W
Weight	90 kg
