D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 86
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Video Output Connector [n] Resolution
This setting applies to Connector [2..3] for MX800 Single, and Connector [3] for MX700 and
MX800 Dual.
Define the resolution and refresh rate for the connected screen.
Requires user role: ADMIN
Default value: Auto
USAGE:
xConfiguration Video Output Connector n Resolution: Resolution
where
Resolution : Auto/1280_720_50/1280_720_60/1920_1080_50/1920_1080_60/1920_1200
_50/1920_1200_60
Auto: The system will automatically try to set the optimal resolution based on negotia-
tion with the connected monitor.
1280_720_50: The resolution is 1280 x 720, and the refresh rate is 50 Hz.
1280_720_60: The resolution is 1280 x 720, and the refresh rate is 60 Hz.
1920_1080_50: The resolution is 1920 x 1080, and the refresh rate is 50 Hz.
1920_1080_60: The resolution is 1920 x 1080, and the refresh rate is 60 Hz.
1920_1200_50: The resolution is 1920 x 1200, and the refresh rate is 50 Hz.
1920_1200_60: The resolution is 1920 x 1200, and the refresh rate is 60 Hz.
xConfiguration Video Presentation DefaultSource
Define which video input source to use as a default presentation source. This setting may be
used by the API and 3rd party user interfaces, but is not relevant when using Touch 10 or the
TRC6 remote control.
Requires user role: USER
Default value: 3
USAGE:
xConfiguration Video Presentation DefaultSource: D efaultSource
where
Defa ultSource : 1/2/3/4
The video input source to use as default presentation source.
xConfiguration Video Selfview Default Mode
Define if the main video source (self-view) shall be displayed on screen after a call. The position
and size of the self-view window is determined by the Video Selfview Default PIPPosition and
the Video Selfview Default FullscreenMode settings respectively.
Requires user role: ADMIN
Default value: Current
USAGE:
xConfiguration Video Selfview Default Mode: Mode
where
Mode : Off/Current/On
Off: self-view is switched off when leaving a call.
Current: self-view is left as is, i.e. if it was on during the call, it remains on after the call;
if it was off during the call, it remains off after the call.
On: self-view is switched on when leaving a call.
xConfiguration Video Selfview Default FullscreenMode
Define if the main video source (self-view) shall be shown in full screen or as a small picture-
in-picture (PiP) after a call. The setting only takes effect when self-view is switched on (see the
Video Selfview Default Mode setting).
Requires user role: ADMIN
Default value: Current
USAGE:
xConfiguration Video Selfview Default Fullscreen Mode: FullscreenMode
where
FullscreenMode : Off/Current/On
Off: self-view will be shown as a PiP.
Current: The size of the self-view picture will be kept unchanged when leaving a call, i.e.
if it was a PiP during the call, it remains a PiP after the call; if it was fullscreen during the
call, it remains fullscreen after the call.
On: The self-view picture will be shown in fullscreen.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco TelePresence MX700 Specifications

General

Product Type	Video conferencing system
Frame Rate	Up to 60 fps
Display	Dual 55-inch LCD
Audio	Integrated speakers and microphones
Video Standards	H.264
Network	Ethernet
Connectivity	HDMI, USB
Control	Touch 10 control unit
Video Resolution	1080p at 60 fps
Zoom	12x optical zoom
Codec	H.264
Network Protocols	SIP
Power Consumption	300W
Weight	90 kg
