D15335.02 Cisco TelePresence MX700 and MX800 API Reference Guide CE8.0, FEBRUARY 2016.
Copyright © 2016 Cisco Systems, Inc. All rights reserved. 37
Cisco TelePresence MX700 and MX800
API Reference Guide
xConfiguration Audio Input HDMI [n] Mode
This setting applies to HDMI [2..3] for single camera systems, and to HDMI [3] for dual camera
systems.
Define if the audio channels on the HDMI input shall be enabled. The HDMI inputs have two
audio channels.
Requires user role: ADMIN
Default value: On
USAGE:
xConfiguration Audio Input HDMI n Mode: Mode
where
Mode : Off/On
Off: Disable audio on the HDMI input.
On: Enable audio on the HDMI input.
xConfiguration Audio Input Line [1..4] Equalizer ID
Select the equalizer ID of the audio source that is connected to the line input.
Requires user role: ADMIN
Default value: 1
USAGE:
xConfiguration Audio Input Line n Equalizer ID: ID
where
ID : Integer (1..8)
Set the equalizer ID.
xConfiguration Audio Input Line [1..4] Equalizer Mode
Define the equalizer mode for the audio source that is connected to the line input.
Requires user role: ADMIN
Default value: Off
USAGE:
xConfiguration Audio Input Line n Equalizer Mode: Mode
where
Mode : Off/On
Off: No equalizer.
On: Enable the equalizer for the audio source that is connected to the line input.
xConfiguration Audio Input Line [1..4] VideoAssociation MuteOnInactiveVideo
The audio source can be associated with a video source on the video input connector, and
you can determine whether to play or mute audio depending on whether the video source is
presented or not. By default, audio is not muted.
Requires user role: ADMIN
Default value: Line [1, 2]: On Line[3, 4]: Off
USAGE:
xConfiguration Audio Input Line n VideoAssociation MuteOnInactiveVideo:
MuteOnInactiveVideo
where
MuteOnInactiveVideo : Off/On
Off: The audio source is not associated with a video source. The audio will be played
locally and to far end regardless of whether the video source is presented.
On: The audio source is associated with a video source. The audio will be played
(locally and to far end) when the associated video source is presented. The audio will
be muted when the video source is not presented.
Introduction
About the API
xConfiguration
Appendices
xCommand
xStatus

xConfiguration

Cisco TelePresence MX700 Specifications

General

Product Type	Video conferencing system
Frame Rate	Up to 60 fps
Display	Dual 55-inch LCD
Audio	Integrated speakers and microphones
Video Standards	H.264
Network	Ethernet
Connectivity	HDMI, USB
Control	Touch 10 control unit
Video Resolution	1080p at 60 fps
Zoom	12x optical zoom
Codec	H.264
Network Protocols	SIP
Power Consumption	300W
Weight	90 kg
