xConfiguration Audio Input Line [1..4] VideoAssociation VideoInputSource
The audio source can be associated with a video source on the video input connector.
Requires user role: ADMIN
Default value: Line [1, 2]: 4 Line[3, 4]: 1
USAGE:
xConfiguration Audio Input Line n VideoAssociation VideoInputSource:
VideoInputSource
where
VideoInputSource : 1/2/3/4/5
Select the video input connector to associate the audio source with.
xConfiguration Audio Input Line [1..4] Channel
Define whether the audio source on the line input is a mono signal or part of a multichannel
signal.
Requires user role: ADMIN
Default value: Left
USAGE:
xConfiguration Audio Input Line n Chan nel: Channel
where
Channel : Left/Mono/Right
Left: The Audio Line input signal is the left channel of a stereo signal.
Mono: The Audio Line input signal is a mono signal.
Right: The Audio Line input signal is the right channel of a stereo signal.
xConfiguration Audio Input Line [1..4] Level
Define the level of the audio source on the line input connector.
See the Audio Level table in the Physical Interface Guide for Cisco TelePresence SX80 for a
complete overview of the values represented in dB.
Requires user role: ADMIN
Default value: 10
USAGE:
xConfiguration Audio Input Line n Level: Level
where
Level : Integer (0..24)
Select a value between 0 and 24, in steps of 1 dB.
xConfiguration Audio Input Line [1..4] Mode
Define the mode for the audio input line.
Requires user role: ADMIN
Default value: On
USAGE:
xConfiguration Audio Input Line n Mode: Mode
where
Mode : Off/On
Off: Disable the Audio Line input.
On: Enable the Audio Line input.
