StateColorLED
• Steady—CIMC and the CPU are both operating normally.
• Blinking—The CPU is operating normally, and CIMC is booting up.
GreenPower
• Steady—CIMC is operating normally, and the CPU is powered down.
• Blinking—CIMC is in the process of booting up, and the CPU is powered down.
Amber
Left LED shows the speed of the Ethernet cable:
• 1 Blink—10 Mb/s speed.
• 2 Blinks—100 Mb/s speed.
• 3 Blinks—1 Gb/s speed.
GreenGE Port
LEDs
Right LED shows whether the link is established.
• Steady—Link is established.
• Off—No link is established.
Green
6
This is memory installed on the DIMM 0 slot.
7
This is the DIMM 1 slot.
8
This is the DIMM 2 slot.
Basic Workflow for Installing the E-Series Server or the SM E-Series NCE in the SM Slot
Procedure
PurposeCommand or Action
Action
Step 1
Reference Topic
Step 2
Tools and Equipment Required for Installation,
on page 25
Gather the required tools and equipment.
Step 3
Removing the Blank Faceplate from the
Router’s SM Slot, on page 26
Remove the blank faceplates from the SM slots
that you want to use.
Step 4
Preparing the Router’s SM Slot for E-Series
Server or SM E-Series NCE Installation, on
page 26
Depending on the type of server that you want
to install either remove or install the slot
divider.
Step 5
Installing the E-Series Server or the SM
E-Series NCE into the Router, on page 29
Install the E-Series Server or SM E-Series NCE
into the router.
Step 6
Verifying E-Series Server or SM E-Series NCE
Installation, on page 32
Verify the E-Series Server or SM E-Series NCE
installation.
Step 7
Tools and Equipment Required for Installation
• Number-1 Phillips screwdriver or a small flat-blade screwdriver
• ESD-preventive wrist strap
• Tape to secure DC circuit breaker handle—Applicable for routers that use DC power
Cisco UCS E-Series Servers and the Cisco UCS E-Series Network Compute Engine Hardware Installation Guide
25
Basic Workflow for Installing the E-Series Server or the SM E-Series NCE in the SM Slot
