Figure 7: Internal Components of the Double-Wide E-Series Server
CMOS battery (resides inside the battery
protector)
2Memory DIMM slots1
Hard disk drives (HDD0 and HDD1)4(Optional) PCIe assembly
Available for HDD2, FCoE port, or 4 Gigabit Ethernet
ports.
3
Double-Wide E-Series Server LEDs
The following table lists the double-wide E-Series Server LEDs and describes the LED colors and states.
Table 16: Double-Wide E-Series Server LEDs
StateColorLED
No memory is installed in this socket.OffM0
6
Memory M0 is installed.Green
Memory M0 is installed, but fault is detected.Amber
Cisco UCS E-Series Servers and the Cisco UCS E-Series Network Compute Engine Hardware Installation Guide
23
Double-Wide E-Series Server LEDs
