HDD2CMOS battery (located under the daughter card)1
SD0
The SD0 card contains the Cisco Integrated
Management Controller (CIMC) software
and must always be present.
Note
4Memory DIMM slots (located under the
daughter card)
3
NIM E-Series NCE LEDs
The following table lists the NIM E-Series NCE LEDs and describes the LED colors and states.
Table 18: NIM E-Series NCE LEDs
StateColorLED
• Steady—CIMC and the CPU are both operating normally.
• Blinking—The CPU is operating normally, and CIMC is booting up.
GreenPower
• Steady—CIMC is operating normally, and the CPU is powered down.
• Blinking—CIMC is in the process of booting up, and the CPU is powered
down.
Amber
Steady—Operation is normal.
Note
If DRAM is not detected, the SYS LED still displays solid green.
Note
• Blinking—System is booting before entering the EFI shell.
GreenSYS
Fault is detected on the processor.Amber
Blinks when the CIMC is operating normally.
GreenIMC
Blinks when the SSD is operating normally.GreenSSD
Left LED shows the condition of the traffic:
• Blinking—Traffic is detected.
• Off—There is no traffic.
GreenGE Port
LEDs
Right LED shows whether the link is established:
• Steady—Link is established.
• Off—No link is established.
Green
Basic Workflow for Installing the NIM E-Series NCE in the NIM Slot
Procedure
PurposeCommand or Action
Action
Step 1
Reference Topic
Step 2
Cisco UCS E-Series Servers and the Cisco UCS E-Series Network Compute Engine Hardware Installation Guide
56
NIM E-Series NCE LEDs
