Before You Begin
When a modem is connected to the auxiliary port, a remote user can dial in to Cisco VG310 or Cisco VG320
and configure it. Use the console cable and the DB-9-to-DB-25 connector adapter that comes with the accessory
kit.
For information on cabling, see Cable Specifications and Information, on page 69.
Procedure
Step 1
Connect the RJ-45 end of the adapter cable to the AUX port on the voice gateway.
Step 2
Connect the other end of the cable to the connector on the modem.
See the figure in LAN and Power Cables, on page 35.
Connecting a Gigabit Ethernet Port to a Gigabit Ethernet Switch
Procedure
Step 1
Connect the cable from a Gigabit Ethernet port to an available port on the Gigabit Ethernet switch.
Step 2
If required, connect the second cable.
Ports and Cabling
The following table summarizes typical WAN, LAN, and voice connections for your Cisco VG310 or Cisco
VG320 voice gateway. For more information on cabling, see Cable Specifications and Information.
Table 11: WAN, LAN, and Voice Connections
CableConnectionPort Type, ColorPort or Connection
Category 5 or higher
Ethernet
Ethernet hub or Ethernet
switch
RJ-45, yellowEthernet
Cisco VG310 and Cisco VG320 Voice Gateways Hardware Installation Guide
OL-31292-01 43
Installing the Cisco VG310 and Cisco VG320 Voice Gateways
Connecting a Gigabit Ethernet Port to a Gigabit Ethernet Switch

Cisco VG310 Specifications

General

Number of Ports	24 FXS ports
Network Protocols	SIP, MGCP, H.323
Form Factor	Rack-mountable
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-4 to 149°F (-20 to 65°C)
Power Supply	AC 100 to 240 VAC, 50 to 60 Hz
Ethernet Ports	2 x 10/100/1000 Ethernet ports
Humidity	10 to 90% non-condensing
Compliance	FCC, CE, UL
