Cisco VG310 User Manual

CONTENTS
Preface Preface ix
Related Documentation ix
Obtaining Documentation x
Conventions x
Obtaining Technical Assistance xi
Submitting a Service Request xi
Definitions of Service Request Severity xii
Obtaining Additional Publications and Information xii
CHAPTER 1 Overview of the Cisco VG310 and Cisco VG320 Voice Gateways 1
Introduction to Cisco VG310 and Cisco VG320 Analog Voice Gateways 1
Front Panel View 2
Back Panel View 2
Locating the Product Serial Number 3
Interfaces and Service Capabilities of Cisco VG310 and Cisco VG320 3
Physical Description and LEDs 4
Gigabit Ethernet Ports and LED Indicators 7
Port Numbering Conventions 8
Hardware Features 8
Real-Time Clock 8
Built-In Interface Ports 8
USB Serial Console Port 9
Removable and Interchangeable Modules and Cards 9
Supported Voice Interface Cards and Voice WAN Interface Cards 10
Periodic Inspection and Cleaning 10
Software Elements 10
Configuration Connections 10
Cisco VG310 and Cisco VG320 Voice Gateways Hardware Installation Guide
OL-31292-01 iii

Cisco VG310 Specifications

General

Number of Ports	24 FXS ports
Network Protocols	SIP, MGCP, H.323
Form Factor	Rack-mountable
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-4 to 149°F (-20 to 65°C)
Power Supply	AC 100 to 240 VAC, 50 to 60 Hz
Ethernet Ports	2 x 10/100/1000 Ethernet ports
Humidity	10 to 90% non-condensing
Compliance	FCC, CE, UL
