C-4
Catalyst 3560 Switch Hardware Installation Guide
OL-6337-07
Appendix C Connecting to DC Power
Connecting to DC Power
Figure C-3 Attaching the Ground Lug Assembly Over the RPS Connector
Figure C-4 Attaching the Ground Lug to the Ground Lug Hole
1 Ground hole location
274668
1
