Chapter 2 Printer Operation
Normal Operating Mode
LED Functions
In addition to normal operating mode,
when an abnormal condition is detected
in the printer, an alarm sounds and the
LED lights up (red) to indicate the type
of error. The LCD indicates the error
message.
Table of Alarm and Error Indications
Item LED LCD
Printing possible (no error)
Lights up
(green)
Ready
Stop or Pause key on operation panel
pressed
Lights up
(green)
Pause
Head temperature - high temperature
abnormality
Lights up (red)
Alarm
Head Hot
Head temperature - low temperature
abnormality
Lights up (red)
Error
Head Cold
PF motor temperature abnormality Lights up (red)
Error
PFMotor Hot
Ribbon motor temperature abnormality Lights up (red)
Error
RBMotor Hot
Cutter motor temperature abnormality Lights up (red)
Alarm
Cutter Hot
Head open Lights up (red)
Error
Head Open
Paper end Lights up (red)
Error
Paper End
Paper out (paper position undetectable) Lights up (red)
Error
Paper Load
Paper jam Lights up (red)
Error
Paper Jam
Head low resistance value abnormality Lights up (red)
Alarm
Head Check
Ribbon end Lights up (red)
Error
Ribbon End
Ribbon feed error Lights up (red)
Error
Ribbon Run
Serial communications error
(receiving buer overrun)
Lights up (red)
Error
Serial Over Run
Serial communications error (parity) Lights up (red)
Error
Serial Parity
Serial communications error (framing) Lights up (red)
Error
Serial Framing
System error Lights up (red)
Error
System Fail
*Auto-cutter abnormality (foreign object
etc.)
Lights up (red)
Error
Cutter Fail
*Applicable only when using the optional auto cutter
LED

Citizen CL-E730 Specifications

General

Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Core diameter	75 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Maximum roll diameter	200 mm
Supported paper width	12.5 - 118 mm
Ethernet LAN	Yes
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Display	LCD
Product color	Black
LED indicators	Status
Flash memory	16 MB
Internal memory	32 MB
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	100 - 230 V
Power consumption (standby)	2.9 W
Power consumption (printing)	72 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	458 mm
Width	250 mm
Height	261 mm
Weight	11000 g
