Citizen CL-E730 User Manual

33
Chapter 2 Printer Operation
Mode Settings
Turning on the power while pressing keys in the following combinations
starts various functions.
Mode Key operation
HEX dump mode Turning power on while pushing the Stop key.
Self print mode Turning power on while pushing the Feed key.
Menu list print mode and
Menu setup mode
Turning power on while pushing the MENU key.
HEX Dump Mode

When using label media
Turn on printer power while pushing the Stop key. If the LED lights up
and the LCD indicates “Hex Dump Mode” and “Label Media”, release
the Stop key, and then the printer enters HEX DUMP mode.

When using continuous media
Turn on printer power while pushing the Stop key. If the LED lights up
and the LCD indicates “Hex Dump Mode” and “Label Media”, and then
changed to “Hex Dump Mode” and “Cont. Media”, release the Stop key,
and then the printer enters HEX dump mode.
DUMP LIST
* To exit HEX Dump Mode, turn o the power to the printer then turn the
power on again (restart).
Operation panel (p.18)

Citizen CL-E730 Specifications

General

Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Core diameter	75 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Maximum roll diameter	200 mm
Supported paper width	12.5 - 118 mm
Ethernet LAN	Yes
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Display	LCD
Product color	Black
LED indicators	Status
Flash memory	16 MB
Internal memory	32 MB
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	100 - 230 V
Power consumption (standby)	2.9 W
Power consumption (printing)	72 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	458 mm
Width	250 mm
Height	261 mm
Weight	11000 g
