Citizen CL-E730 User Manual

26
Chapter 2 Printer Operation
Setting the Media
Installing the Media
1. Push the large blue-head open lever to release the head
unit, and then lift the sensor arm by hand as shown below.
Head unit
Large blue-head open lever
Sensor arm
2. Load the media in the Media holder bar.
First, insert the media holder bar into the media, and then,
attach the media holder guide. As orientation of the media
varies according to the orientation of the printing surface,
load the media by referring to step 5.
Media holder bar
Media holder guide
3. Face the front side of the printer and set the media in such a
manner that the media holder guide comes on the right side
of the media.
When lifting the media, use the handles on the media holder
placed on either side.
4. Move the media roll so it is touching the leftside of the
housing.
Note: Do not try to hold the media too tightly with these guides as it
will cause the printer to jam during printing.
Media Sizes (p.25)

Citizen CL-E730 Specifications

General

Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Core diameter	75 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Maximum roll diameter	200 mm
Supported paper width	12.5 - 118 mm
Ethernet LAN	Yes
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Display	LCD
Product color	Black
LED indicators	Status
Flash memory	16 MB
Internal memory	32 MB
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	100 - 230 V
Power consumption (standby)	2.9 W
Power consumption (printing)	72 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	458 mm
Width	250 mm
Height	261 mm
Weight	11000 g
