Citizen CL-E730 User Manual

52
Chapter 2 Printer Operation
Quick Setup of the Print Method
The print method (thermal transfer method/direct thermal method) can
be set using operation panel in addition to Menu Setup mode.
Setting method
Keep the Feed key held down. Each time the Pause key is pushed, the
printer switches between thermal transfer mode and direct thermal
mode.
Hold Press/Release

If thermal transfer is selected, the buzzer sounds once and the LCD
briey displays “Print Method, TT” before returning Ready status.

If direct thermal is selected, the buzzer sounds twice and the LCD
briey displays “Print Method, DT” before returning Ready status.
Note: Changes will remain in eect even after the power is turned o.
Be sure to always shut o the operation of print before changing a
setting. You cannot change a setting during printing (including pause).
Caution
Menu Setup Mode (p.35)

Citizen CL-E730 Specifications

General

Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Core diameter	75 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Maximum roll diameter	200 mm
Supported paper width	12.5 - 118 mm
Ethernet LAN	Yes
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Display	LCD
Product color	Black
LED indicators	Status
Flash memory	16 MB
Internal memory	32 MB
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	100 - 230 V
Power consumption (standby)	2.9 W
Power consumption (printing)	72 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	458 mm
Width	250 mm
Height	261 mm
Weight	11000 g
