Citizen CL-E730 User Manual

53
Chapter 2 Printer Operation
Emulation Auto Detect: Cross-Emulation
TM
Ordinarily emulation switching is conducted in the Menu Setup mode.
However, switching can also be conducted using the Emulation Auto-
Detection function outlined below.
The following message is displayed on the LCD when the Zebra®
emulation (ZPI2) command is detected during Datamax® emulation.
ZPI2 detected.
No Yes
Switch
No Yes
emulation?
No Yes
By selecting “Yes” the printer will reboot and automatically switch to ZPI2
emulation. The printer will return to the Ready status if “No” is selected.
The following message is displayed in the LCD when the Datamax®
command is detected during Zebra® emulation.
DMX detected.
No Yes
Switch
No Yes
emulation?
No Yes
By selecting “Yes” the printer will reboot and automatically switch to
Datamax® emulation (DM4/DMI/DPP). The printer will return to the Ready
status if “No” is selected.
Menu Setting Table (p.41)

Citizen CL-E730 Specifications

General

Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Core diameter	75 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Maximum roll diameter	200 mm
Supported paper width	12.5 - 118 mm
Ethernet LAN	Yes
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Display	LCD
Product color	Black
LED indicators	Status
Flash memory	16 MB
Internal memory	32 MB
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	100 - 230 V
Power consumption (standby)	2.9 W
Power consumption (printing)	72 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	458 mm
Width	250 mm
Height	261 mm
Weight	11000 g
