Citizen CL-E730 User Manual

29
Chapter 2 Printer Operation
7. Lift the sensor arm up temporarily and adjust the media
guide. Align the media with the left xed media guide, align
the right movable media guide with the media width, and
lower the sensor arm.
Movable media
guide
Fixed media guide
Sensor arm
8. Push the head close knob to lower and lock the head unit.
Be sure to always push the head close knob to lock the head
unit. Align it with the width of the media that has been set,
then set the media width and media thickness adjustment
dials. See “Chapter 3 Printer Adjustments”.
Head unit
Head close knob
Media thickness
adjustment
Media width adjustment
9. With the power switched on, push the Feed key to feed the
media.
It will halt at the next print start position.
Setting the Media
Media Thickness Adjustment
(p.59)
Media Width Adjustment
(p.60)

Citizen CL-E730 Specifications

General

Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Core diameter	75 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Maximum roll diameter	200 mm
Supported paper width	12.5 - 118 mm
Ethernet LAN	Yes
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Display	LCD
Product color	Black
LED indicators	Status
Flash memory	16 MB
Internal memory	32 MB
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	100 - 230 V
Power consumption (standby)	2.9 W
Power consumption (printing)	72 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	458 mm
Width	250 mm
Height	261 mm
Weight	11000 g
