Citizen CL-E730 User Manual

40
Chapter 2 Printer Operation
Global Conguration Sets
The printer can store three sets of conguration settings that can be
recalled quickly and easily.
Each “Cong Set” (1, 2 or 3) can contain completely dierent conguration
settings for all menu parameters.
For example, “Cong Set 1” could be congured for 6 ips print speed, print
darkness 10.“Cong Set 2” next could be 5 ips continuous card media with
black mark, print darkness 12.
The ability of having three sets of settings is ideal for someone who prints
on dierent media types regularly, for example in a label printing bureau.
Global cong settings can be printed using the “Test Mode, Print Pattern,
Global Cong” menu option. It will also display the currently active “Cong
Set”:
Global Menu Settings
Active Configuration Setting
Config 1 Config 2 Config 3
[PageSetup Menu]
Print Speed 6 5 4
Print Darkness 10 12 12
Darkness Adjust +00 +00 +00
Print Method TT TT TT
Continuous Media Length 04.00inch 04.00inch 04.00inch
Vertical Position +0.00inch +0.00inch +0.00inch
Horizontal Position +0.00inch +0.00inch +0.00inch
Vertical Image Shift +0.00inch +0.00inch +0.00inch
Auto Side Shift 00dots 00dots 00dots
Media Sensor See Through Reflect See Through
Small Media Adjustment Off Off Off
Small Media Length 1.00inch 1.00inch 1.00inch
Symbol Set PM PM PM
[System Setup Menu]
Sensor Level 1.7V 1.7V 1.7V
Paper End Level 2.80V 2.80V 2.80V
Error Reporting On Printing On Printing On Printing
Buzzer Select On On On
Metric/Inch Inch Inch Inch
Max Media Length 10.00inch 10.00inch 10.00inch
Settings Lock Off Off Off
Keyboard Lock Off Off Off
LCD Standby Off Off Off
Standby Timer 5 min 5 min 5 min
Control Code STD STD STD
Emulation Select DM4 DM4 DM4
[After Print Menu]
AutoConfigure On On On
Function Select Tear Tear Tear
Paper Position +0.00inch +0.00inch +0.00inch
Menu Key Action Enters Menu Enters Menu Enters Menu
Mode Settings

Citizen CL-E730 Specifications

General

Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Core diameter	75 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Maximum roll diameter	200 mm
Supported paper width	12.5 - 118 mm
Ethernet LAN	Yes
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Display	LCD
Product color	Black
LED indicators	Status
Flash memory	16 MB
Internal memory	32 MB
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	100 - 230 V
Power consumption (standby)	2.9 W
Power consumption (printing)	72 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	458 mm
Width	250 mm
Height	261 mm
Weight	11000 g
