Citizen CL-E730 User Manual

45
Chapter 2 Printer Operation
Top Menu Sub Menu Default Menu Remarks
Network Address ** – 000.000.000.000 to
255.255.255.255
Setting xed IP address of the LAN board.
Subnet Mask ** – 000.000.000.000 to
255.255.255.255
Setting xed subnet mask value of the LAN
board.
Gateway Address ** – 000.000.000.000 to
255.255.255.255
Setting xed default gateway address of
the LAN board.
BOOTP ** – On
O
Setting the BOOTP of the LAN board.
DHCP ** – On
O
Setting the DHCP of the LAN board.
WLAN Mode *** – Auto
Ad-Hoc
Infrastructure
Wireless LAN mode setting.
WLAN Channel *** – 01 to 14 Wireless LAN channel setting.
WLAN SSID *** – Max. 32 characters SSID setting of Wireless LAN.
Machine
Information
[Machine Info]
Model Number – CL-E*** Displays the model name.
Boot Version – *.* Displays the boot version
ROM Version – ******** Displays the ROM version.
ROM Date – **/**/** Displays the date the ROM was prepared.
ROM CheckSum – **** Displays the check sum of the ROM
FPGA Version – *.* Displays the FPGA version
Head Check – OK
NG
Displays the results of the head check.
Print Counter – ****.*** km Displays the print counter.
Service Counter – ****.*** km Displays the service counter.
Cut Counter – ******* Displays the cut count.
Sensor Monitor – *.* V Displays the sensor level.
Option Interface
[Option I/F]
– None
RS-232C
LAN
IEEE1284
Displays the presence/absence of the
optional interface.
• If Dip Switch 1 is ON in RS-232C interface,
RS-232C (DIP SW) will be displayed. (See
“Interface” in the section of Appendix)
RS-232C Baud – – If Dip Switch 1 is ON in RS-232C interface,
the communication condition set in Dip
Switch will be displayed.
RS-232C Parity – –
RS-232C Length – –
RS-232C Stop bit – –
RS-232C X-ON – –
MAC Address – – Displays MAC Address
**

If the multi-function LAN board is mounted, or during web monitor function.
***When the multi-function wireless LAN board is available and when Web monitor is operating.
Note: Settings related to interface are enabled after restart or after power is connected again.
Mode Settings
[Datamax® Emulation]

Citizen CL-E730 Specifications

General

Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Core diameter	75 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Maximum roll diameter	200 mm
Supported paper width	12.5 - 118 mm
Ethernet LAN	Yes
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Display	LCD
Product color	Black
LED indicators	Status
Flash memory	16 MB
Internal memory	32 MB
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	100 - 230 V
Power consumption (standby)	2.9 W
Power consumption (printing)	72 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	458 mm
Width	250 mm
Height	261 mm
Weight	11000 g
