Citizen CL-E730 User Manual

64
Chapter 3 Printer Adjustments
2. Make adjustment according to the position at which looses
occur in the ribbon, by using the following procedure.

In case of looseness on the side opposite the adjustment knob
Turn the front adjustment knob to the left to remove the looseness,
then make a test print to ensure that the ribbon is not wrinkled.
If wrinkles occur, adjust the back (feeding side) ribbon guide
adjustment cam also. Carry out the ribbon guide adjustment by
referring to the next page.
Front balance adjustment knob

In case of looseness on the ribbon guide shaft
Turn the front adjustment knob to the right to remove the looseness,
then make a test print to ensure that the ribbon is not wrinkled.
If wrinkles occur, adjust the back (feeding side) ribbon guide
adjustment cam also. Carry out the ribbon guide adjustment by
referring to the next page.
Front balance adjustment knob
Adjusting the Ribbon

Citizen CL-E730 Specifications

General

Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Core diameter	75 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Maximum roll diameter	200 mm
Supported paper width	12.5 - 118 mm
Ethernet LAN	Yes
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Display	LCD
Product color	Black
LED indicators	Status
Flash memory	16 MB
Internal memory	32 MB
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	100 - 230 V
Power consumption (standby)	2.9 W
Power consumption (printing)	72 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	458 mm
Width	250 mm
Height	261 mm
Weight	11000 g
