Citizen CL-E730 User Manual

66
Chapter 3 Printer Adjustments

When ribbon loosing occurs in the front ribbon left-right
balance adjustment knob side

Lower the ribbon guide adjustment cam and increase the inclination
of the ribbon guide shaft of the side where there is no loose in the
ribbon (adjustment knob side).
Ribbon guide adjustment cam
4. Once the angle is appropriate, tighten all the screws that
were loosened.
5. Perform print and conrm that there are no wrinkles.
If there are wrinkles, make adjustments again.
NOTE: If the media thickness adjustment dial and media width
adjustment dial are not appropriate, wrinkles may occur in the
ribbon. If wrinkles occur despite adjusting the ribbon guide, adjust
these dials also.
Adjusting the Ribbon
Media Width Adjustment
(p.60)
Media Thickness Adjustment
(p.59)

Citizen CL-E730 Specifications

General

Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Core diameter	75 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Maximum roll diameter	200 mm
Supported paper width	12.5 - 118 mm
Ethernet LAN	Yes
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Display	LCD
Product color	Black
LED indicators	Status
Flash memory	16 MB
Internal memory	32 MB
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	100 - 230 V
Power consumption (standby)	2.9 W
Power consumption (printing)	72 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	458 mm
Width	250 mm
Height	261 mm
Weight	11000 g
