Citizen CL-E730 User Manual

79
Appendixes
Using and Connecting to LinkServer
1
Start a Web browser on a computer connected to the same network as
the printer and input the IP address set in the printer to be connected
in the address bar (red frame part). (If IP address is '169.254.1.10', input
'http://169.254.1.10'.)
There are three types of rights for the LinkServer, i.e. User, Operator,
and Administrator. The display menu can be changed based on
the user privileges so as to limit the operation of the LinkServer
accordingly.
The home screen for User rights will be displayed when connecting.
Home screen (User rights)
2
A conrmation screen is displayed when one presses the [LOG IN]
button.
Conrmation screen
• The factory default setting for Operator authentication
The user name and password to be entered are both "Operator".
• The factory default setting for Administrator authentication
The user name and password to be entered are both"Admin".
Interfaces

Citizen CL-E730 Specifications

General

Color	No
Print technology	Direct thermal / Thermal transfer
Maximum resolution	300 x 300 DPI
Maximum print height	- mm
Maximum printing width	104 mm
Core diameter	75 mm
Media thickness	0.0635 - 0.254 mm
Maximum media length	4013 mm
Maximum roll diameter	200 mm
Supported paper width	12.5 - 118 mm
Ethernet LAN	Yes
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Display	LCD
Product color	Black
LED indicators	Status
Flash memory	16 MB
Internal memory	32 MB
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	100 - 230 V
Power consumption (standby)	2.9 W
Power consumption (printing)	72 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	458 mm
Width	250 mm
Height	261 mm
Weight	11000 g
