Citizen CLP-621 Technical Manual

Chapter 5. Parts Lists
CLP-621 & CLP-631 5-10
PARTS LIST for CLP-621 & CLP-631 TITLE: Base Unit Sheet No. 1/3
Drawing No. 2 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks @
2-1 Unit, Ribbon JM34706-0 1
-2 Screw, PH, M3.0x6 E00530-060WF 2
-3 Screw, PHT (BH2T), M3.0x14 E11230-140F 4
-4 Unit, Mechanism 621 JM49802-0 1 For CLP-621
-4 Unit, Mechanism 631 JM49812-0 1 For CLP-631
-5 Wire Tie C6701-202# 2 8432 L=100
-6 SA, Centro Cable JM67725-1 1
-7 Screw, PHT (ST#3), M3.0x5 E11130-050F 4
-8 Unit, Main PCB (With ROM)-IT JM66802-0 1 For CLP-621/CSA
-8 Unit, Main PCB (With ROM)-IT JM66821-0 1 For CLP-631/CSA
-8 Unit, Main PCB (With ROM)-MT JM66801-0 1 For CLP-621/CSE
-8 Unit, Main PCB (With ROM)-MT JM66819-0 1 For CLP-631/CSE
-8 Unit, Main PCB (With ROM)-ZI JM66809-0 1
For CLP-621Z/CSA
-8 Unit, Main PCB (With ROM)-631ZI JM66823-0 1 For CLP-631Z/CSA
-8 Unit, Main PCB (With ROM)-ZM JM66808-0 1 For CLP-621Z/CSE
-8 Unit, Main PCB (With ROM)-631ZM JM66822-0 1 For CLP-631Z/CSE
-9 Sheet, Main PCB JM44116-0 1
-10 Screw, PHT (BH2T), M3.0x8 E11230-080F 7
-11 Plate, Main PCB 621 JM44122-0 1
-12 Unit, Centro PCB JM66825-1 1
CLP-621Z & CLP-631Z
are identical to CLP-621
& CLP-631 except for the
firmware and character
generator.

Citizen CLP-621 Specifications

General

USB port	No
RS-232 interface	Yes
Optional connectivity	Ethernet
USB 1.1 ports quantity	1
USB 2.0 ports quantity	0
Connectivity technology	Wired
Flash memory	2 MB
Certification	UL, C-UL, FCC class A, CCC, CE Marking
Internal memory	8 MB
Number of fonts	2
Built-in barcodes	PDF417, UPC-A, UPC-E
Built-in processor	32 Bit RISC
Mean cycles between failures (MCBF)	1000
Power consumption	2400 mA
Power requirements	100 - 240V, 50 / 60Hz
Compatible operating systems	Windows 2000, XP, Vista
Core diameter	25.4 mm
Ribbon length	360 m
Media thickness	0.0635 - 0.254 mm
Maximum label length	812 m
Maximum roll diameter	127 mm
Supported paper width	19.5 - 118 mm

Weight and Dimensions

Depth	114 mm
Width	91 mm
Height	104 mm
