Citizen CLP-621 Technical Manual

Chapter 5. Parts Lists
CLP-621 & CLP-631 5-11
PARTS LIST for CLP-621 & CLP-631 TITLE: Base Unit Sheet No. 2/3
Drawing No. 2 Rev. No. 0
Location Part Name Part No.
Q'ty/
Unit
Remarks @
2-13 Screw, BHT (ST), M3.0x5 E14030-050WF 2
-14 Washer, EXT.T, 3 (NI) E50730-000WF 3
-15 Lock Screw (Inch) HFS-4S-B1W C6390-049# 2 For CSA
-15 Lock Screw (M2.6) C6390-050# 2 For CSE
-16 Plate, Earth JM54101-0 1
-17 Sheet, Earth L JM44115-0 1
-18 Sheet, Earth R JM44114-0 1
-19 Cable, Ope-Pane JM67900-1 1
-20 SA, Core JM59701-0 1
-21 Cushion, Ope-Pane Cover JM59904-0 1
-22 Cushion, Ope-Pane Cable JM59903-0 1
-23 Unit, Control Panel JM56801-0 1
-24 Nut, M4 E40140-000F 2
-25 Leg, Case L F JM59902-0 2
-26 Case L JM56201-0 1
-27 Leg, Case L R JM59901-0 2
-28 Screw, BH, M4.0x4 (NI) E00540-040WF 2
-29 Washer, EXT.T, 4 (NI) E50740-000WF 2
-30 Screw, BH (N), M3.0x6 E00530-060WF 1
-31 Sheet 2, Main PCB JM44123-0 1

Citizen CLP-621 Specifications

General

USB port	No
RS-232 interface	Yes
Optional connectivity	Ethernet
USB 1.1 ports quantity	1
USB 2.0 ports quantity	0
Connectivity technology	Wired
Flash memory	2 MB
Certification	UL, C-UL, FCC class A, CCC, CE Marking
Internal memory	8 MB
Number of fonts	2
Built-in barcodes	PDF417, UPC-A, UPC-E
Built-in processor	32 Bit RISC
Mean cycles between failures (MCBF)	1000
Power consumption	2400 mA
Power requirements	100 - 240V, 50 / 60Hz
Compatible operating systems	Windows 2000, XP, Vista
Core diameter	25.4 mm
Ribbon length	360 m
Media thickness	0.0635 - 0.254 mm
Maximum label length	812 m
Maximum roll diameter	127 mm
Supported paper width	19.5 - 118 mm

Weight and Dimensions

Depth	114 mm
Width	91 mm
Height	104 mm
