— 44 —
GS / m
[Function] Printing the Download, Bit Image
[Code] <1D>H<2F>H<m>
[Range] {0 =< m =< 03(Hex)}
[Outline] Prints download bit image in a mode specified by m.
• Modes can be selected by m are shown below.
[Caution] • When data exist inside the print buffer, this command is ignored.
•When a download bit image has not been defined, this command is ignored.
•A portion of a download bit image exceeding one line length is not printed.
[See Also] GS *
[Sample Program] Refer to the programming example and print result of GS *.
Dot Density in Dot Density in
Vertical Direction Horizontal Direction
0 Normal mode 203 DPI 203 DPI
1 Double wide mode 203 DPI 101 DPI
2 Double high mode 101 DPI 203 DPI
3 Double wide/ 101 DPI 101 DPI
double high mode
m (Hex) Name
[Print Results]
To Next Page
