Citizen PMU2300III Series

PMU2300III Series Service Manual
- 42 -
Q’ty
Loc.No. Part No. Parts Name
PN PB
Remakes
66 SEC-4790 CA212-17Cord Assy (RoHS) 500/L 1 1 Parallel I/F
67
ZF66815-00F
ZF66818-00F
SA, Main PCB III UBU
SA, Main PCB III UBJ
1 1 USB I/F
69 ZF66701-00F SA Power Cable 1 1
70 C10216
Bag (0.08 × 120 × 200)
1 1
72 80-0276 Caution Hot (SEC2049) 1 1
408 ZF24701-00F SA, Chassis 1 1
ZF24124-00F CHASSISZF24701 1 1 Not supplied
ZF22003-00F GUIDE, PINZF24701 2 2 Not supplied
409 ZF24125-00F COVER, PLATE 1 1
410 ZF24126-00F HOLDER, PCB SENSOR 1 1
411 ZF24127-00F HOLDER, WIRE 1 1
412 ZF24128-00F GUIDE, PLATE MIDDLE 1 1
413 ZF24129-00F COVER, SUS SHEET 1 1
406 ZF24130-00F GUIDE, ROLLER FRONT 1 1
401 ZF24133-00F PLATE, SIDE L 1 1
402 ZF24134-00F PLATE, SIDE R 1 1
414 ZF22701-00F SA, PF SHAFT 1 1
ZF22004-00F SHAFT, PF ROLLER 1 1 Not supplied
ROLLER 1 (NBR) 1 1 Not supplied
ROLLER 2 (NBR) 2 2 Not supplied
404 ZF22006-00F SHAFT, ROLLER FRONT 1 1
415 ZF20201-00F GEAR, PRESENTER 1 1
416 ZF22201-00F ROLLER, SUB 2 2
417 ZF22202-00F ROLLER, PRESSURE 1 1
418 ZF24210-00F COVER, GEAR 1 1
405 ZF22203-00F ROLLER, FRONT 4 4
419 ZF22005-00F WIRE, FRICTION 1 1
420 ZF24902-00F SHEET, MIDDLE 1 1
421 ZF24903-00F SHEET, SENSOR 1 1
407 ZF24905-00F SHEET, ROLLER GUIDE 1 1
422 ZF24906-00F SHEET, ADHESIVE 1 1
423 ZF24907-00F SHEET, SCREW 1 1
