4-1-4. PHU-203T
Loc.No. Part No. Parts Name Q’ty Remakes
7 E11130-060F
Screw. PHT (ST), M3 × 6
7
12 E50130-105F
WASHER, PLANE, 3 × 8 × 0.5
1
50 ZF22001-03F Shaft Paper Holder 1
53 ZF24106-01F Holder PNE 1
55 E00130-030F
Screw. PHT, M3 × 3
4
57 ZF24112-00F Cover PNE Holder 1
56 K-103GN Cord Holder 1
201 ZF24137-00F PLATE, PAPER HOLDER 203L 1
202 ZF24138-00F PLATE, PAPER HOLDER 203R 1
203 ZF24139-00F PLATE, REAR 1
204 ZF24140-00F COVER, LEVER 1
205 ZF22204-00F CORE, PAPER HOLDER 1
206 ZF67708-00F SA, PNE SENSOR 1
207 ZF29903-00F SCREW, SHAFT 1
208 ZF26901-00F STAINLESS BALL CHAIN (TM-14-2) L:200 mm 1
209 600403-00 TENSION, LEVER 1
210 550045-00 TENSION, BAR 1
211 70-0016 EXT SPRING-03 1
212 E11130-100F
SCREW, PHT (ST), M3 × 10
1
