288
In the event of a breakdown
Jumpy_en_Chap08_En-cas-de-panne_ed01-2016
Stowing
F Press the latches A and slide them inwards
to release the box.
F Lift the box slightly then pull it as far as it
will go to take it past bar 1.
F
Then, lift the box upwards to take it past
bar 2.
F
Unclip the fixings B on the cover, then
open it for access to the tools.
Opening
Removing
Pull on the box to check that it is secure
in its housing.
F
Offer up the box with the front inclined
upwards.
F To take it past bar 2, push the box in and
down.
F
To take it past bar 1, raise the box slightly
then push it fully in.
F
Refit the cover on the box and clip the
fixings B.
F
Once the box is fully home in its housing,
push it against the floor carpet then slide
the latches A outwards to secure it.
