27NX404E

English

Installation Notes

Connection Notes

•Useonlythesuppliedparts.

Ifunspeciedpartsareused,theymaycausedamage.

•Anyholesmadeinthebodyofthevehicleshouldbesealedwitha

silicon adhesive. If exhaust fumes or water penetrates into the vehicle,

this may cause an accident.

•Fastentheboltssecurelywheninstallingtheunit.Iftheboltsareloose

an accident or malfunction could occur.

•Verifywireswithadigitalmulti-meterpriortomakinganyconnections.

Many new vehicles use multiplexed and/or low voltage circuits that can

be damaged if a test light or logic probe is used.

•Connectcablesappropriately.Ifawrongconnectionismade,thismay

causeareoraccident.

•Whenpassingcablesthroughthebodyofthevehicle,usenon-

conductive grommets. If the coatings of the cables are worn out by

rubbing,thismaycauseanaccident,reorashortcircuit.

•Afterwiringcables,xthemwithinsulationtape.

•Besuretoswitchothevehiclewhenconnectingordisconnecting

cords to/from the unit, otherwise an electric shock, injury or accident

may occur.

•Pleasenotethepositionofpipes,tanksandelectricalwiringsbefore

installing the unit into the vehicle; failure in avoiding these may cause a

reormalfunction.

WARNING

•Loomallcablesaccordingtotheinstructionmanual,soasnottohinder

operation.

•Wiretheconnectingcords/cablesawayfromhightemperatureareas.

Ifthecoatingsofthecablesmelt,itcouldcauseanaccident/rebya

short circuit. Take care when wiring in the engine compartment.

•Whenwiringtheconnectingcablesinavehiclewithanairbagsystem,

neverfeedthecablesthroughaplacewhereitmayaecttheoperation

of the airbag. An airbag not operating correctly in an emergency may

cause increased injury.

WARNING

CAUTION

NX404E_QSG 20131205_EN.indd 27 2014-2-12 12:01:19
