Clarion NX404E Quick Start Guide

31NX404E
English
English
Cautions on Wiring
1.Besuretoturnthepowerobeforewiring.
2. Be particularly careful where you route the wires.
Keepthemwellawayfromtheengine,andexhaustpipe,etc.Heatmaydamage
the wires.
3. If the fuse should blow, check to see if the wiring is correct.
If a fuse is blown, replace it with a new one of the same amperage rating as the
original (15A FUSE).
4. To replace the fuse, remove the old fuse on the back of the unit and insert the new
one. (Figure 8)
NOTE:
There are various types of fuse holder. Do not let the battery side touch other metal
parts.
Figure 8
Fuse (15A FUSE)
Fuse holder
CAUTION
After the connection, x the cord by a clamp or insulation
tape for protection.
Installing The GPS Antenna
•DonotinstalltheGPSantennainaplacewhereitmayinterferewiththe
operation of the airbag or hinder the driver’s visual range.
•DonotusethenavigationsystemwiththeGPSantennacordcuto.
The power cables in the cord may be short-circuited.
WARNING
NOTE:
•ThesuppliedGPSantennaisforinstallinginsidethevehicle.Donotinstallitoutsidethe
vehicle.
•InstalltheGPSantennamorethan50cmawayfromthemainunit,otheraudiodevices
suchasCDplayer,andaradardetector.Ifitisinstallednearthesedevices,GPS
reception may be impaired.
•ToimprovetheGPSsignalreception,installtheGPSantennahorizontallyonaatplane.
•DonotwaxorpaintthecoveroftheGPSantenna.Thismayreducetheperformanceof
theGPSantenna.
•InstalltheGPSantennaatleast10cmawayfromthewindshield.
•WipeothedirtofthemountingsurfacebeforeinstallingtheGPSantenna.
•MounttheGPSantenna.Stick
itsurelzonaatplaneofthe
passenger side dashboard
where GPS signal interruption is
minimized.
•WiretheGPSantennacord.
Fasten the cord using the cord
holders.
•Stickthedouble-sidedtapetothe
bottom face of the GPS antenna.
Cord holder
Figure 7
GPS antenna
Bottom face of the GPS
antenna
Double-sidedtape
NX404E_QSG 20131205_EN.indd 31 2014-2-12 12:01:25

Clarion NX404E Specifications

General

Brand	Clarion
Model	NX404E
Category	Car Video System
Language	English
