32 NX404E
English
Note:
*1:ConnectingthePHONEINTERRUPTterminal
Thephoneinterruptwillmutetheaudioiftheleadreceivesanegativeor
groundsignal.
15 A
BACKUPYellow
GND
Black
ILLUMIOrange/White
AUTO ANTBlue
ACCRed
PHONE INTBrown
REMOTEBlue/White
PARKINGGrass-green
REVERSEPurple/White
RR-Purple/Black
RR+Purple
FR-Gray/Black
FR+Gray
FL+White
FL-White/Black
RL+Green
RL-Green/Black
!!!!Warning!!!!
Parking brake safety
device must be
connected for complete
operation
NX404E_QSG 20131205_EN.indd 32 2014-2-12 12:01:25
