Clarion NX505E User Manual

2 NX505E
English
Hard buttons and touch keys
The operation descriptions in this manual, hard buttons on the main unit are indicated by
dotted frames as the example shown below.
Example:
MENU
The unit uses a touch panel system that you can operate simply by touching the screen with
your fingertip.
In this manual, operations performed by touching keys on screen are indicated by the
grayed out keys as the example shown below.
Example: Tuner
Hard button
Touch key
Thank you for purchasing the Clarion NX505E.
●
Please read this owner’s manual thoroughly before operating this equipment.
●
After reading this manual, be sure to keep it on hand for future reference.
●
Check the contents of the enclosed warranty card and keep it carefully with this manual.
●
The provided disc (CD-ROM manual) cannot be played back on this unit.
In particular, read the descriptions in “To Ensure Safe Use.” This describes cautions
to ensure safe use of the unit without inflicting harm or damage on yourself or
others.

P. 5
●
The content of this manual may differ in part with that of the actual product due to
modifications, etc. to the specifications.
●
The content of this manual may be changed in part without notice.
When transferring or reselling the unit or disposing of it, delete (initialize) all data
saved on it to protect your personal information and copyright protection.
Meanings of Symbols Used in This Manual
WARNING
Preparations
This indicates the possibility that failure to
follow this instruction might lead to death
or serious injury.
This explains what must be done
beforehand to operate the product.
CAUTION
Notice
This explains things that may cause injury
if instructions are not followed.
This explains limitations related to
operations.
Attention MEMO:
Though this does not fall under the
category of “WARNING” or “CAUTION”,
this indicates that there is the danger of
money or time being lost.
This explains supplementary information
for mastering use of the unit.

Clarion NX505E Specifications

General

Widescreen	-
Display diagonal	6.2 \
Display resolution	800 x 480 pixels
AM band range	531 - 1602 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, DAB, FM
Built-in camera	No
Lifetime map updates	Roads change, but with Lifetime Map Updates your map will always be up to date. Start fresh every few months by downloading a new edition of the industry's most accurate map. New editions are issued four times per year.
Storage media type	Memory card
Compatible memory cards	MicroSD (TransFlash)
Product color	Black

Weight and Dimensions

Depth	157 mm
Width	178 mm
Height	100 mm
Weight	- g
