Clarke
®
Operator's Manual - Encore S17/L17 Page -31-
Ref. # Part No. Description Qty
1 Page 32 Recovery Tank Assembly 1
2 980651 Washer, Flat 5/16" 8
3 80212A Screw, M8 x 1.25 x 35mm Hex Head 4
4 Page 34 Solution Tank Assembly 1
5 Page 48 Rotary Disk Head Assembly Option 1
6 Page 46 Cylindrical Head Assembly Option 1
7 Page 44 Frame Assembly 1
8 80197A Screw, M8 x 1.25 x 20mm Hex Head 4
9 980652 Washer, Lock 5/16" 4
10 Page 42 Squeegee Assembly 1
11 Page 40 Squeegee Lift Assembly 1
12 80179A Screw, M6 x 1 x 15mm Pan Head 6
13 Page 38 Control Housing Assembly 1
14 Page 36 Electrical Assembly 1
15 30334A Tether 1
16 52570A Clip, Tether 1
NI 40606A Battery, 130AH, 12V Wet Option 2
NI 40605A Battery, 130AH, 12V Dry Option 2
NI 40070A Battery, 100AH, 12V Gel Option 2
NI 41206A Battery Cable (Taper Style) 1
NI 41217A Battery Cable (Ring Style) (use w/gel batteries) 1
NI 61337A Battery Cable Adapter (use w/gel batteries) 2
NI = Not Illustrated
Clarke
®
Encore S17/L17 & S17/L17 Cylindrical
Final Assembly Parts List 11/02
