Clarke
®
Operator's Manual - Encore S17/L17 Page -39-
Clarke
®
Encore S17/L17 & S17/L17 Cylindrical
Control Housing Parts List 2/05
Qty Qty Qty Qty
Ref. # Part No. Description S17 L17 S17 Cyl L17 Cyl
1 962957 Screw, 10-16 x 1/2" 6 6 6 6
3 70352A Membrane Switch 1 1 1 1
4 60979A Control Panel 1 1 1 1
5 52555A Lever Gasket 1 1 1 1
6 60978A Wear Plate 1 1 1 1
7 87036A Washer, Flat #10 3 3 3 3
8 80196A Nut, M5 x .8, Nylock 3 3 3 3
9 40597A Panel Circuit Board 1 1 1 1
10 962330 Screw, 6-32 x 3/8" Pan Head 4 4 4 4
11 30214A Switch Lever 2 2 2 2
12 50961A Spring, Switch 4 4 4 4
13 80192A Screw, M5 x .8 x 16mm, Oval Head 4 4 4 4
14 30213A Switch Housing 2 2 2 2
15 980608 Washer, Flat #6 4 4 4 4
16 40126A Switch Assembly 2 2 2 2
17 80191A Screw, M3.5 x 6 x 10mm, Pan Head 4 4 4 4
18 52556A Reverse Switch - 1 - 1
19 30220A Control Handle, Traverse - 1 - 1
30228A Control Handle, Non-Traverse 1 - 1 -
20 47380A Key Switch - 1 - 1
20B 55413A Key, Spare - 1 - 1
21 80230A Washer, Nylon 1 1 - -
22 87052A Washer, Key Switch - - 1 1
23 41422A Circuit Breaker, 25A 1 2 2 3
24 41433A Circuit Breaker, 40A 1 1 - -
41422A Circuit Breaker, 25A - - 1 1
25 41423A Circuit Breaker, 5A 2 2 2 2
26 80229A Arrow Clip, Nylon 1 1 - -
27 40135A Potentiometer Harness - 1 - 1
28 980666 Washer, Lock 3/8" - 1 - 1
29 60259A Potentiometer Retainer - 1 - 1
30 50962A Control Knob - 1 - 1
31 962262 Screw, Set 8-32 x 1/2" (included in #30) - 1 - 1
32 70080A Plate, Warning 1 1 1 1
33 83010A Rivet, Pop 2 2 2 2
NOTE: indicates a change has been made since the last publication of this manual.
