Clarke
®
Operator's Manual - Encore S17/L17 Page -35-
Ref. # Part No. Description Qty
1 80199A Nut, M6 x 1 Hex Nylock 2
2 980614 Lock Washer, 1/4" Ext. Tooth 10
3 87026A Flat Washer, 1/4" 4
4 40724A Vacuum Motor 1
5 61297B Front Motor Mount 1
6 80179A Screw, M6 x 1 x 15mm, Pan Head 8
7 80180A Screw, M6 x 1 x 30mm, Pan Head 2
8 61298B Rear Motor Mount 1
9 52551A Battery Strap 1
12 52548A Screw Tab 4
13 30221A Front Cover 1
14 80202A Screw, M5 x .8 x 15mm, Pan Head 6
15 87036A Flat Washer, #10 4
16 80196A Nut, M5 x .8 Hex Nylock 4
17 80209A Shoulder Bolt, M5 x 6 x 8mm 2
18 61457A Left Front Cover Bracket 1
19 61456A Right Front Cover Bracket 1
20 30219A Solution Tank 1
21 50248A Hose Clamp 6
22 53607A Elbow, 1/4 NPT x 3/8 1
23 30172A Hose 2
24 51204A Valve, Solution 1
26 820207 Adapter 1
27 30453A Hose 1
28 59614A Battery Drain Valve 1
32 51518A Bushing 2
33 51526A Hosebarb, 3.8 x 90° 2
34 55189A Hosebarb, 1/2 x 90° 2
35 31242A Bushing 2
36 30239A Level, Drain Hose 1
37 30222A Solution Lid 1
38 61280A Drain Hose Hanger 1
39 980603 Lock Washer, #10 Ext. Tooth 4
40 52552A Battery Strap, w/Buckle 1
41 41809A Contact, Connector 2
42 43401A Housing, Connector 2
43 80210A Screw, M6 x 1 x 10mm, Flat Head 2
44 80176A Screw, M5 x .8 x 12mm, Pan Head 2
45 61345A Hinge Bracket 1
46 40817A Brush Mechanism 2
47 53562A Filter Bowl 1
NI 70668A Label, Encore (Front Cover) 1
NI = Not Illustrated
Clarke
®
Encore S17/L17 & S17/L17 Cylindrical
Solution Tank & Front Cover Parts List 9/04
