Clarke
®
Operator's Manual - Encore S17/L17 Page -47-
Clarke
®
Encore S17/L17 Cylindrical
Cylindrical Head Parts List 2/04
Ref. # Part No. Description Qty
1 80198A Nut, M8 x 1.25 Nylock 3
2 980652 Washer, 5/16" Lock 3
3 980692 Washer, 5/16" Flat SS 13
4 80165A Shoulder Bolt, M6 x 8 x 12mm 2
5 980651 Washer, 5/16" Flat 2
6 80199A Nut, M6 x 1 Nylock 8
7 87026A Washer, 1/4" Flat SS 8
8 80196A Nut, M5 x .8 Nylock 2
9 61306A Switch Bracket 1
10 80176A Screw, M5 x . 8 x 12mm Pan Hd 17
11 61080A Head Bracket 1
12 915082 Key, 3/16" Sq. X 3/4" 2
13 50436A Drive Pin 4
14 30230A Debris Tray 1
15 61286A Brush Shaft 2
16 ref. See accessories page, cyl. brush 2
17 61398A Brush Spacer 2
18 61449A Door, L.H. Brush 1
19 52477A Clamping Knob 2
20 80180A Screw, M6 x 1 x 30mm Pan Hd 8
21 30545A Skirt, Brush Door 2
22 30209A Bumper, Brush Door 2
23 30208A Bumper, Belt Cover 2
24 30544A Skirt, Belt Cover 2
25 53399A Flange Bearing 4
26 80179A Screw, M6 x 1 x 15mm Pan Hd 4
27 61282A Cover L.H. Belt 1
28 80214A Screw, M6 x 1 x 12 Hex Head 2
29 980657 Washer, 1/4" Lock 10
30 61396A Motor Pulley 2
31 21058A Brush Housing 1
32 57994A Screw, M6 x 20mm, Hex Head 4
33 61397A Brush Pulley 2
34 52818A Drive Belt 2
35 80178A Shoulder Bolt, M6 x 8 x 30mm 2
36 59932A Front Wheel 2
37 80187A Bolt, M8 x 1.25 x 30mm Hex Hd. 3
38 80177A Shoulder Bolt, M6 x 8 x 60mm 2
39 61448A Roller Bracket 2
40 80208A Screw, M6 x 1 x 10mm Pan Hd 4
41 30049B Wheel, 1 x 2 x 5/16 4
42 30235A Bumper, Housing 1
43 61287A Bumper Retainer 1
44 70465A Label, 17 1
45 61285A Motor Cover 1
46 61283A Door, R.H. Brush 1
47 61450A Cover, R.H. Belt 1
48 77091A Label, Moving Parts 2
49 782002 Clamp, Solution Tube 1
50 50248A Clamp, 3/8 Hose 2
51 10387A Solution Tube Assembly 1
52 61430A Motor 2
53 41602A Housing, Connector 4
54 41601A Contact, Connector 4
55 930113 Rivet, 1/8" 3
56 61288A Tray Rail 1
57 80158A Key, 1/8" Sq. x 1/2" 2
58 53182A Cap, Tube 2
59 80249A Screw, M5-.8 x 12 mm HH 2
60 962262 Screw, Set 8-32 x 1/4 2
