Operator's Manual - Encore S17/L17 Page -45-
Clarke
®
Encore S17/L17 & S17/L17 Cylindrical
Frame Parts List 2/04
Qty Qty Qty Qty
Ref. # Part No. Description S17 L17 S17 Cyl L17 Cyl
1 80199A Nut, M6 x 1, Nylock 5 6 5 6
2 87026A Washer, Flat 1/4" SS 7 17 7 17
3 80204A Nut, M3 x .5 Nylock 2 2 2 2
4 80225A Spring, Front (1.25" long) - - 1 1
54179A Spring, Front (2.25" long) 1 1 - -
5 80196A Nut, M5 x .8 Nylock 1 1 1 1
7 61077A Rear Actuator Bracket 1 1 1 1
8 80164A Shoulder Bolt, M5 x 6 x 20mm 1 1 1 1
9 61075A Actuator 1 1 1 1
10 80165A Shoulder Bolt, M6 x 8 x 12mm 2 2 2 2
11 980651 Washer, Flat 5/16" 2 2 2 2
12 980692 Washer, Flat 5/16" SS 18 18 18 18
13 61074A Lift Bracket 1 1 1 1
14 80173A Bolt, M6 x 1 x 65mm Hex Head 1 1 1 1
15 80195A Screw, M6 x 1 x 20mm Hex Head 2 3 2 3
16 980614 Washer, Lock 1/4" Ext Tooth - 2 - 2
17 61302A Static Strap - 1 - 1
18 47422B Switch, Wisker 1 1 1 1
19 80203A Screw, M3- x 5 x 30mm Pan Head 2 2 2 2
20 59610A Solution Valve 1 1 1 1
21 51526A Hosebarb, 90°, 3/8 x 3/8 1 1 - -
52635A Hosebarb, 90°, 3/8 x 1/2 - - 1 1
22 30311A Hose 1 1 - -
23A 61455A Axle, Non-Traverse 1 - 1 -
23B 61076A Transaxle - 1 - 1
24 80197A Screw, M8 x 1.25 x 20mm Hex Head 12 10 12 10
25 57423A Snap Ring 2 - 2 -
26 87616A Washer, Nylon 4 - 4 -
27A 61436A Wheel, Non-Traverse 2 - 2 -
27B 61437A Wheel, Traverse - 2 - 2
28 980205 Washer, 5/16" Fender 2 - 2 -
29 60289A Transaxle Clamp - 2 - 2
30 81104A Nut, 1/4-20 ESNA SS - 8 - 8
31 80198A Nut, M8 x 1.25 Nylock 8 8 8 8
32 61079A Head Bracket 1 1 1 1
33 61460A Caster Assembly 1 1 1 1
34 61073A Main Frame 1 1 1 1
35 80223A Nut, M10 x 1.5 Nylock 1 1 1 1
36 980645 Washer, Flat 3/8" 1 1 1 1
37 80226A Spring, Rear (2" long) 1 1 1 1
38 980652 Washer, Lock 5/16" 2 - 2 -
