Operator's Manual - Encore S17/L17 Page -37-
Clarke
®
Encore S17/L17 & S17/L17 Cylindrical
Electrical Parts List 11/02
Ref. # Part No. Description Qty Qty
S17 L17
1 80179A Screw, M6 x 1 x 15mm, Pan Head 6 6
2 980614 Washer, Lock 1/4" Ext. Tooth 12 12
3 30097A Insulator 1 1
4 40635A Squeegee Switch 1 1
5 980607 Washer, Lock #6 Ext. Tooth 2 2
6 962980 Screw, 6-32 x 1, Pan Head 2 2
7 30287A Strain Relief 1 1
8 52548A Screw Tab 2 2
9 30175A Squeegee Cam 1 1
10 40614A Battery Charger, 115V, 50/60 Hz 1 1
40615A Battery Charger, 230V, 50/60 Hz 1 1
11 40611A Cord, Power Supply 115V 1 1
40609A Cord, Power Supply 230V, European 1 1
12 980692 Washer, Flat 5/16" SS 2 2
13 438360 Squeegee Lift Spring 1 1
14 80178A Shoulder Bolt, M6 x 8 x30mm 1 1
15 80202A Screw, M5 x .8 x 15mm, Pan Head 1 1
16 60975A Squeegee Cable 1 1
17 85389A Screw, 3/8-16 x 5/8 1 1
18 980666 Washer, 3/8" Ext. Tooth 1 1
19 60976A Squeegee Lever 1 1
20 52557A Squeegee Knob 1 1
21 40631A Traverse Harness - 1
22 80186A Eyebolt, #10-24 1 1
23 40592A Traverse Controller - 1
24 80221A Screw, M4 x .7 x 20mm, Pan Head 3 3
25 40630A Main Harness, Traverse - 1
40629A Main Harness, Non-Traverse 1 -
26 193951 Grommet, 8.5" 1 1
27 80205A Screw, M5 x .8 x 20mm, Pan Head 1 1
28 80204A Nut, M3 x .5, Nylock 2 2
29 40169A Solenoid, Vacuum 1 1
30 80208A Screw, M6 x 1 x 10mm, Pan Head 6 6
31 41811A Contactor, Main 1 1
32 40612A Red Battery Cable 1 1
33 80222A Screw, M4 x .7 x 10mm, Pan Head 2 2
34 40633A Relay, DPDT, 115V 1 1
40634A Relay, DPDT, 230V 1 1
35 41810A Contactor, Brush 1 1
36 40613A Black Battery Cable 1 1
37 46106A Rectifier 1 1
38 40626A Terminal Block 1 1
39 80206A Screw, M3 x .5 x 20mm, Pan Head 2 2
40 980603 Washer, Lock #10 Ext. Tooth 2 2
41 80169A Nut, M5 x .8 Hex 2 2
42 80199A Nut, M6 x 1, Nylock 1 1
43 60265A Nut Plate 1 1
44 60977A Squeegee Lift Mount 1 1
45 61084A Electrical Panel, Traverse - 1
61332A Electrical Panel, Non-Traverse 1 -
46 52562A Strain Relief Bushing 1 1
47 80196A Nut, M5 x .8 Nylock 1 1
48 912216 Fuse, 15A 1 1
49 43006A Fuse Holder 1 1
50 77094A Label, Ground 1 1
51 77092A Label, Gases & Chemicals 1 1
