Operator's Manual - Encore S17/L17 Page -49-
Clarke
®
Encore S17/L17
Rotary Disk Head Parts List 7/03
Ref. # Part No. Description Qty Qty
S17 L17
1 41602A Housing, Connector 1 1
2 41601A Contact, Connector 1 1
3 40591A Brush Motor 1 1
4 20014A Motor Shim 1 1
5 87026A Washer, Flat 1/4" 2 2
6 80199A Nut, M6 x 1 Nylock 2 2
7 80165A Shoulder Bolt, M6 x 8 x 12mm 2 2
8 980651 Washer, Flat 5/16" 2 2
9 80196A Nut, M5 x .8 Nylock 3 3
10 61306A Switch Bracket 1 1
11 980692 Washer, Flat 5/16" 2 2
12 80249A Screw, M5 x .8 x 12mm Hex Head 2 2
13 61078A Motor Mount Bracket 1 1
14 98451A Washer, Lock 7/16" 4 4
15 80184A Bolt, M10 x 1.5 x 25mm Hex Head 4 4
16 20308A Motor Adaptor 1 1
17 980679 Washer, Flat 3/4" 1 1
18 980210 Washer, Impeller 1 1
19 980652 Washer, Lock 5/16" 1 1
20 80197A Screw, M8 x 1.25 x 20mm Hex Head 1 1
21 30216A Upper Brush Housing 1 1
22 30217A Lower Brush Housing 1 1
23 70667A Label, 17 1 1
24 66550A Pin Assembly 1 1
25 80224A Shoulder Bolt, M5 x 6 x 16mm 2 2
26 980643 Washer, Flat 2 2
27 920278 Nut, 1/2-20 SS Hex 1 1
28 61289A Motor Cover Rod 1 1
29 52515A Bearing Sleeve 1 1
30 87036A Washer, Flat #10 1 1
31 80227A Extension Spring 1 1
32 980645 Washer, Flat 3/8" 2 -
33 80202A Screw, M5 x .8 x 15mm, Pan Head 1 1
34 80169A Nut, M5 x .8 Hex 2 2
35 77091A Label, Moving Parts 1 1
