Operator's Manual - Encore S17/L17 Page -43-
Clarke
®
Encore S17/L17 & S17/L17 Cylindrical
32" Squeegee Parts List 6/04
Ref. # Part No. Description Qty
1 80252A Screw, ¼-20 x 1 Hex SS 4
2 980657 Washer, ¼ Lock 4
3 60243A Bracket, Squeegee Wheel 2
4 30049B Wheel, Squeegee 4
5 81104A Nut, ¼-20 2
6 60254A Bolt, Shoulder
5
/16x 2¼ 2
7 50958A Ring,
3
/8 ID Snap 2
8 30048A Wheel, Guide, 4 Inch Diameter 2
9 60234A Channel, Squeegee Weldment 32” 1
10 50835A Latch, Squeegee Clamp 1
11 930086 Rivet, 3/16 x .450 Aluminum 2
12 60232A Strap, Clamp, Squeegee Retainer 32 1
13 30067A Blade, Rear, Gum Rubber, 32” 1
14 30047A Spacer, Squeegee 32 1
15 30066A Blade, Front Ribbed 32” 1
16 80011A Screw,
3
/8-16 x 3 2
17 81301A Nut,
3
/8-16 Jam SS 2
18 34260B Gasket 1
19 25201A Knob 2
20 60358A Shim, Squeegee Wheel 2
21 61370A Weight, Squeegee 4
22 80280A Nut, Squeegee Backup 2
